Model

SP-POS58IV-S

SP-POS58IV-P

SP-POS58IV-U

Interface Type

RS-232

LPT

USB

Print

Printing Method

Thermal Line

Printing Speed

70mm / second or 20 lines / second

Resolution

8 dots/mm, 384 dots/line

Printing Width

48mm

Character

Character Set

IBM Character Set II, GB2312-80

Print Font

ANK: 9 x 17 / 12 x 24; GB2312-80: 24 x 24

Character per Line

32

Paper Spec

Paper Type

Thermal Paper

Paper Width

57.5± 0.5mm

Paper Roll Diameter

Max: 83.0mm

Roll Core Inner Dia.

13mm minimum

Paper Thickness

0.06 to 0.07mm

Reliability

MCBF

5 million lines

TPH

100km

Auto Cutter

Not Applicable

Barcode Types

UPC-A,UPC-C, EAN-13, EAN-8, CODE39,

ITF, CODEBAR, CODE93, CODE128

Emulation

ESC/POS

Paper Supply Method

Drop-in Paper Load

Driver

Windows 98 / 2000 / NT / XP/ Vista / 7

Sensor

Paper End Sensor

Drawer Port

1 Port

Auto Cutter

N/A

Housing Color

Beige / Black

Power Supply (Adapter)

AC100 ~240V ± 10%(included) DC 12V, 2A+

Net / Gross Weight

1.0kg / 1.7kg

Printer Dimension

200 x 138 x 120 mm (W x L x H)

Operation Environment

0 ~ 50° C , R.H. 10~80%

Storage Environment

-20 ~ 60° C , R.H. 10~90%

In the interest of improvement, specifications may change prior to notice
